Orbit Form Builder

← All plugins

Free
Official
Panel kit
Dark mode ready

Visually build Orbit forms from every field and layout, then collect answers with handlers.

Visit on GitHub

Homepage Changelog PyPI

pip install almasix-orbit-form-builder

Installs—
Stars1

Author: Almasix
Orbit versions: 0.5
Package: almasix-orbit-form-builder
License: MIT
Python: >=3.11
Listed: September 28, 2026

forms
form-builder
surveys
panel
tenancy

What it does

Design dynamic forms inside your Orbit panel using the full Orbit field and layout catalog. Publish a definition, share a fill page, and store answers with optional email, webhook, or custom callable handlers. Multi-tenant panels keep definitions and submissions scoped by tenant.

Install

pip install almasix-orbit-form-builder

from almasix_orbit_form_builder import FormBuilderPlugin, bootstrap_memory_store

bootstrap_memory_store()
panel.plugin(FormBuilderPlugin.make().navigation_group("Forms"))

Full README: almasix-orbit-form-builder.

Orbit form builder designer with palette, definition editor, and live preview

Documentation

View source

Orbit Form Builder

Visually build Orbit forms from every Orbit field and layout, publish them, and collect answers with pluggable handlers.

Install

pip install almasix-orbit-form-builder

from almasix_orbit_form_builder import FormBuilderPlugin, bootstrap_memory_store

bootstrap_memory_store()  # or DatabaseFormStore() after migrating

panel.plugin(FormBuilderPlugin.make().navigation_group("Forms"))

For database storage, create the tables from almasix_orbit_form_builder.migrations.migration_statements() and:

from almasix_orbit_form_builder import DatabaseFormStore, set_form_store

set_form_store(DatabaseFormStore())

Requires almasix-orbit ≥ 0.5.3 (custom pages mount Conduit hosts via get_conduit_host()).

What you get

Surface	Purpose
Form builder page	Generous visual canvas (grids/fields look like themselves), filterable component bank, drag-drop with drop-zone highlights, property modal, preview modal with live validation, draft/publish
Definitions resource	List metadata (JSON is readonly — edit structure on the builder page)
Submissions resource	Inspect answers
Fill page (`/forms/fill`)	Respondents submit published forms

Designer

Filter or browse the Components bank; drag onto the canvas or into a layout drop zone (or click to add into the selection).
Root fields follow Form columns (default 2). Nested Grid / Group show their own column count.
Click a field or layout (or Edit) to open the properties modal — label, placeholder, validation rules, columns, etc.
Preview opens a modal with a fillable form (validates; does not store).
JSON / Handlers are optional drawers — definition JSON stays a readonly export.

Definitions

Forms are stored as JSON that mirrors Orbit’s to_dict() shape:

{
  "components": [
    {
      "type": "Section",
      "heading": "Contact",
      "schema": [
        {
          "type": "Grid",
          "columns": 2,
          "schema": [
            { "type": "TextInput", "name": "email", "label": "Email", "required": true },
            { "type": "TextInput", "name": "phone", "label": "Phone" }
          ]
        }
      ]
    }
  ]
}

build_form(definition) hydrates that document into a live almasix.orbit.forms.Form. Callables (relationship loaders, live hooks) are not embedded in JSON — register named handlers in your app and reference them from field config when needed.

Answer handlers

Every submit is always persisted first. Then configured handlers run in order. Configure them in the designer (store / email / webhook / callable), for example:

{
  "handlers": [
    { "type": "store" },
    { "type": "email", "to": "ops@example.com", "subject": "New lead" },
    { "type": "webhook", "url": "https://example.com/hooks/forms" },
    { "type": "callable", "name": "my_crm" }
  ],
  "success_message": "Thanks — we got it."
}

from almasix_orbit_form_builder import register_handler


def push_to_crm(form, submission, config): ...


register_handler("my_crm", push_to_crm)

Tenancy

When the panel has tenancy enabled, the plugin binds set_tenant_resolver so definitions and submissions are keyed by tenant_id (empty string = global). Use .without_tenant_resolver() to skip.

Limits

Designer is a nested tree with drag-drop (not a free-form pixel canvas).
Relationship / upload-heavy fields work with static serializable props; advanced callables need named handlers.
Fill page lives at forms/fill — set form_slug on the host (or open via the UI) for the published slug.

License

MIT

This plugin is maintained by the Orbit team.
